Installation
Circuit breakers
All 100 V and 115 V models have 1 circuit breaker. All 230 V models have 2.
Input power Model / Ratings
Voltage DH2 DH4 DH8
100 V
5 A 10 A 15 A
115 V
4 A 7 A 15 A
230 V
2 A + 2 A 4 A + 4 A 6 A + 6 A
Weight
Dry weight:
► DH2: 38 lb (17 kg)
► DH4: 58 lb (26 kg)
► DH8: 74 lb (34 kg)
Size
Dimensions for overall exterior, including items protruding from main unit, unless specied otherwise.
Dimension
Model
DH2 DH4 DH8
Width 14.50 in (368 mm) 21.75 in (553 mm) 21.75 in (553 mm)
Height with baskets lowered 16.25 in (413 mm) 16.25 in (413 mm) 16.25 in (413 mm)
with baskets raised 23.00 in (584 mm) 23.00 in (584 mm) 23.00 in (584 mm)
Depth 15.50 in (394 mm) 15.50 in (394 mm) 22.50 in (572 mm)
Interior volume
Overall chamber volume
► DH2: 2.2 U.S. gallons (8.2 liters)
► DH4: 4.75 U.S. gallons (18 liters)
► DH8: 8.5 U.S. gallons (32 liters)
Maximum capacity (per basket compartment)
► DH2: 2 units
► DH4: 4 units
► DH8: 8 units
Operating conditions
Indoor use only
Altitude (maximum): 2000 m
Ambient temperature range: 5 °C to 32 °C
Relative humidity (maximum for ambient temperature): 80% for temperatures up to 31 °C, decreasing
linearly to 50% at 40 °C
