Helo OT 2 PS-1 User Manual

40
Sensor
410 C D
A 205 205 50
90 580 min 1200
min
min 1900
20
Heater
Distance (mm) Heater A C D 3kW 50 280 80 X X 4,5 80 280 100 X X 6 100 280 150 X X 8 130 300 200 X X 9 130 300 200 X
The sensor must be installed as shown in the illustration below. Digression from these instructions may cause overheating and risk for fire
- Sensor installation - Removing of the cover
Sensor
Upper bench
Lower bench
1418-2-1517-3
1418-2-1517-1
