Part 2: Overview
Top panel: Page reference
1 POWER switch Turns the instrument on and off 24
2 MASTER VOLUME fader Controls volume for speakers and
headphones (when connected)
24, 25
3 BRIGHTNESS fader Control the sound of the piano 24
4 REVERB button Sets on the room ambience of the sound 27
5 CHORUS button Turns on the sound modulation 26, 27
6 TOUCH button Sets the touch sensitivity 27
7 DEMO button Activates/deactivates demo song mode 29
8 METRONOME button Turns the metronome on and off 28
9 TRANSPOSE buttons Activate/deactivate transpose mode 27
10 TEMPO buttons Adjusts metronome tempo 27, 28
11 LCD-Display Shows various informations
12 VOICE SELECTION buttons Selects voice presets; also used for
demo song settings
26, 29
13 SEQUENCER Activates/deactivates record and
playback functions
28
Rear panel:
14 MIDI In/Out jacks Connect the piano to other MIDI
compatible instruments
29, 30
15 PEDAL jack Connects to cable from pedal unit 25
16 LINE IN/OUT jack Connect external sound equipment 25
17 HEADPHONE jack Connects a pair of headphones 25
18 POWER jack Connects to power supply 24
