16
sensors or attempt to cycle
the Horizontal Dock without a
MacBook positioned in the tray.
Port Alignment
The Horizontal Dock’s four-point
positioning system and
alignment sensors will ensure
that the MacBook is properly
seated in the tray and ready for
docking. Be sure the ports of
the MacBook are free of debris
before inserting the MacBook
into the Horizontal Dock. Remove
any connectors, dongles or
memory cards that do not  t
completely  ush with the side of
the MacBook before using the
Horizontal Dock.
Never force the MacBook into
the Horizontal Dock, or try to pry
or forcibly remove the MacBook
from the dock.
Audio
The Horizontal Dock
is equipped with two
TRRS style 3.5 mm
audio ports. Both audio ports
can provide microphone input
and stereo output. The audio
inputs and outputs for each
