HANDRAIL TUBE
Art. No. 35149
ere are several ways in which the handrail can
be installed, and this depends on area of use.
In cases, e.g. of instalment of several poles in
succession, in combination with the handrail tubes,
a walking path can be created. e tubes can also
be installed at different angles, in which case they
can be used as handrails, e.g. in a staircase.
e contents in the delivery received therefore
depend on the desired configuration.
A
When collapsible handrail tubes are installed be-
tween two Gripo poles, the accessory package will
consist of two universal connectors and one
handrail tube.
B
C
e largest clamp
B 2
is attached to the Gripo pole.
For the smallest clamp
B 4
, which also holds the
handrail tube, to be rotatable, the tooth washer
B 3
must be removed (do not use). en the universal
connector is reassembled.
B 6 B 5 B 4
B 3
B 2
B 1
