Page 10 For technical questions, please call 1-888-866-5797. Item 64984
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Pan head Self-Tapping Screw 8
2 Cover cap 1
3 Socket pan head triplex screw 4
4 Housing 1
5 Brush component 1
6 Rubber column 1
7 Cross pan head screw 2
8 Deep groove ball bearing 1
9 Rotor 1
10 Deep groove ball bearing 2
11 Stator 1
12 Pan head screw 5
13 Trigger 1
14 Windshield 1
15 Screw 1
16 Washer 1
17 Screw 1
18 Right handle 1
19 Spacer 1
20 Bracket 1
21 Compression spring 1
22 Self-Tapping Screw 2
23 Fixing sleeve 1
24 Elastic cylindrical pin 2
25 Hook 1
26 Baseboard 1
27 Guide plate 1
28 Flat washer 2
29 Thin head semi-tubular rivet 1
30 Left handle 1
31 Gear box 1
32 Seal Ring 1
33 Compression spring 1
34 Lockpin 1
35 Button 1
36 Shaft sleeve 1
37 Flange head-tapping screw 1
38 Electronic component 1
39 Inner socket-tapping screw 1
40 Hex socket set screw 2
Part Description Qty
41 Guide plate 1
42 Oval head semi-tubular rivet 1
43 Knob component 1
44 Flat washer 1
45 Guide ruler 1
46 Cross countersunk screw 4
47 Spring 1
48 Knob component 1
49 Screw 1
50 Guide ruler 1
51 Wrench 1
52 Cylindrical pin 1
53 Button 1
54 Reverse lock button spring 1
55 Shield 1
56 Cover cap 1
57 Spring pin 1
58 Absorber 1
59 Socket screw 1
60 Circlip 1
61 Gear 1
62 Circlip for hole 1
63 Wave washer 1
64 Output shaft 1
65 Oil seal 1
66 End cover 1
67 Socket countersunk head screw 8
68 Inner flange 1
69 Outer flange 1
70 Saw blade bolt 1
71 Torsion spring 1
72 Shield 1
73 Stop collar 1
74 Guard handle 1
75 Socket pan head screw 2
76 Compound slot pan head screw 1
77 Dust chute 1
78 Blade 1
79 Hex Key (not shown) 1
