PARTS LIST AND DIAGRAM
Parts List
[*63 '/CO62.3214 l3-
1 Hammer Rod Protector 1
2 Ø28 Retaining Ring 1
3 Move Limited Ring 1
4 Chuck Ring 1
5 Flex Spring 1
6 Ø32 Retaining Ring 1
7 Plum Blossom Chuck 1
8 Move Limited Ring 1
9 Cover 1
10 SØ6 Steel Ball 4
11 Front Cover 1
12 O Ring Ø27.5×Ø2 1
13 Lock Bit Bead 2
14 Hammer Bit Sheath 1
15 Impact Hammer 1
16 Hammer Ring 1
17 Impact Piston 1
18 O Ring Ø23.2x3.5 1
19 Cylinder 1
20 Cylinder Cover 1
21 Hex Socket Bolt M6×25(12.9) 8
22 Ø6×Ø10.5 Flat Washer 4
23 O Ring Ø44×Ø2.2 1
24 O Ring Ø22×Ø4 1
25 O Ring Ø24×Ø1.8 1
26 Gas Press Piston 1
27 Piston Pin Ø8×26 1
28 Connecting Rod Asm. 1
29 M4×12 Hex Socket Bolt 4
30 Oil Tank Cover 1
31 O Ring Ø55×Ø2.5 1
32 Crank Shaft 1
33 4×12 Key 1
34 Ø47 Retaining Ring 1
35 6303 RS Ball Bearing 1
36 O Ring Ø46.5×Ø2 1
37 Oil Seal Ring Ø17×Ø30×6 1
38 Gearbox 1
39 Gear 1
40 6001 RS Ball Bearing 1
41 Inner Cover 1
42 Ø5 Spring Washer 4
43 M5×16 Hex Socket Bolt 4
44 Ø5×14 Pin 1
45 Seal Ring 1
46 O Ring Ø31.5XØ2 1
47 6201 RS Ball Bearing 1
[*63 '/CO62.3214 l3-
48 Armature 1
49 Armature Insulation Washer 1
50 608ZT CW Ball Bearing 1
51 ST4.8×65 Screw 2
53 Stator 1
54 Fan Guide 1
55 Housing Asm. 1
56 Ø6 Spring Washer 4
57 Carbon Brush Wire 2
58 Carbon Brush 2
59 Coil Spring 2
60 Screw ST3.5x12 4
61 Fan Cover 1
62 ST4.2×16 Screw 8
63 Bottom Support Seat 1
64 Bottom Shock Absorption Jacket 1
65 Main Handle 1
66 Top Support Seat 1
67 Hex Socket Bolt M5×12 2
68 Top Shock Absorption Jacket 1
69 Shock Absorption Spring 1
70 Shock Absorption Pivot 1
71 Washer 2
72 M6×14 Hex Socket Bolt 2
73 Trigger 1
74 ST5.5×25 Machine Screw 1
75 Main Handle Cover 1
76 Screw ST5.5x38 1
79 Indicator Subassembly 1
80 Carbon Brush Indicator 1
81 Cord Clip 1
82 Cord Armor 1
83 Cord 1
84 Side Handle Asm. Steel Tie 1
85 Ø5×23 Spring Column Pin 1
86 Abnormity Bolt 1
87 Front Handle Asm. Base 1
88 Front Handle Asm. Cover 1
89 Front Handle Asm. 1
90 Grease Tube 1
92 Front Cover Washer 2mm 1
93 Woolen Washer Ø7.2×7 1
94 Woolen Ring Ø17×4.5 1
95 O Ring Ø31xØ5.25 1
96 Rubber Cushion 1
97 Seal Ø15.5xØ23.2x3.3 2
