PARTS LIST AND DIAGRAM
Parts List
[*63 '/CO62.3214 l3-
1 Hammer Rod Protector 1
2 Chuck Ring 1
3 Steel Wire Block Ring Ø27xØ2 1
4 Support Patch 1
5 Shock Absorption Ring 1
6 Move Limited Ring 1
7 Insert Block 2
8 Change Plate 1
9 Support Ring Spring 1
10 Support Ring 1
11 Position Ring 1
12 Ø6.5 Steel Ball 8
13 Hex Socket Bolt M8×30 4
13A Ø8 Spring Washer 4
14 Flange Cover 1
15 O-Ring Ø63.5×Ø2.6 1
16 Hammer Rod Sleeve 1
17 O-Ring Ø31.6×Ø2.5 1
18 Ø41 Retaining Ring 1
19 Oil Seal Ring Ø32×Ø42×7 1
20 Impact Pin 1
21 O-Ring Ø22×Ø11 1
22 Control Plate 1
23 Fixed Distance Sleeve 1
24 O-Ring Ø35×Ø3 1
25 Impact Block 1
26 O-Ring Ø30.4×Ø5 2
27 Cover 1
28 Control Sleeve 1
29 Control Sleeve Spring 1
30 Cylinder 1
31 Piston Pin Ø10×38 1
32 Piston 1
33 Connecting Rod Asm. 1
34 Impact Body 1
35 Screw ST6.3x32 4
36 Oil Tank Cover 1
36A Adorn Cover 1
37 Rubber Washer 1
38 Felt Ring 1
39 Bolt M5×12 4
40 Shell Cover 1
41 O-Ring Ø79×Ø2.8 1
42 Eccentric Gear Asm. 1
43 6002 RS Ball Bearing 2
44 Distance Ring 1
46 Needle Bearing Nk20×28×13 1
47A Seal Ring Asm. Ø31xØ20x6.4 1
47B Seal Ring Asm. Ø31xØ19.7x6.8 1
[*63 '/CO62.3214 l3-
48 Housing Asm. 1
49 Cord Clip 1
50 ST4.2×18 Screw 2
51 Speed Knob 1
52 Main Handle Cover 1
53 Trigger 1
54 Carbon Brush Indicator 1
55 Handle 1
56 ST5.5×45 Screw 1
57 ST4.2×22 Screw 1
58 Cord Protector 1
59 Power Cord 1
62 Stator 1
64 Carbon Brush Bracket 1
65 Spring 2
66 Metal Contact Plate 1
67 Screw ST3.5x16 3
67A ST3.5x12 Screw 5
68 Metal Insert 2
69 Carbon Brush 2
70 Carbon Brush Wire 2
72 Armature 1
73 Bearing Sleeve 1
74 6200 LUV CW Ball Bearing 1
74A Ø10 Retaining Ring 1
75 O-Ring Ø29xØ2.6 1
76 Screw Ring 1
77 Protected Cover 1
78 Bearing Cover 1
79 Screw ST5.5x25 10
80 Disk With Gap 2
81 Clamping 2
82 Fixed Belt 1
83 Bolt M8×130 1
84 Front Handle 1
85 Handle Knob 1
86 Nut M8 x 6.4mm 1
87 Function Knob Cover 1
91 Oil Bottle Ø35×135 1
92 Main Handle Platen 2
93 Main Handle Seat 1
94 Shock Absorption Jacket 1
95 Shock Absorption Ferrule 2
96 Shock Absorption Spring 1
97 Spring Rack 1
98 Screw M6×50(Ø18) 2
103 Ø42 Retaining Ring 1
104 Stator Block 2
