1. Terminals Introduction
1.1 About DCU
①：LED1，DCU working condition light；
②：LED2，DCU communicating with the platform indicator light；
③：LED3，DCU communicating with the microinverter indicator light；
④：DRM Port；
⑤：Ethernet Port；
⑥：RS485 Port；
⑦：DC 5V Input Port；
⑧：AP Button；
⑨：Reset Button.
Specific functions of each port see Section 1.3 and Section 1.5.
