16
11 – TECHNICAL SPECIFICATIONS
Glance L
Maximum Average Power (kW) 6.6
Average Peak Power (kW) 10.0
Average Efficiency (%) (Note Maximum efficiency on low burn 67%) 60
Average Emmissions ( Particulates g/kg) 1.2
Maximum log size (mm) 500
Flue Diameter (Ø) 150 (6”)
Minimum Chimney height (m) from Hearth 4.6m
Flue outlet (Optional rear flue requires additional blanking ribs Vertical
Weight (Kg) 150
Outside air inlet pipe diameter (Ø mm) 80
Minimum diameter of the outside air inlet pipe (Ø mm) 80
Maximum length of the outside air inlet pipe from outside (m) 8m
In the case of other dimensions consult your Dealer or the Manufacturer (Approximate Values)
ATTENTION! Your heater should not be used as an incinerator and no other types of fuel should be
used (plastic, chipboard…). Use recommended fuels only.
Do not use wood washed ashore from the sea as fuel (driftwood).
The salt contained in it will react in the combustion process and release acid that will damage the iron
and steel.
