32
|
GB
m ATTENTION!
The device and the packaging material are not
children‘s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or su󰀨ocating!
8. Assembly / Before commissioning
8.1 Fitting the wheels (7) (enclosed accessories bag A)
Undo the hexagon screw on the bracket (Fig. 3 (1))
until the wheel axle ts into the bracket.
Now guide the wheel axle into the bracket (Fig. 3 (2)).
Fully tighten previously loosened screw.
Now t the wheels and washer.
Secure the wheels on the axle with a split pin.
Finally t the small wheel cap. Repeat this process
on the other side.
8.2 Fitting the table (5)
Undo the star-grip screw (Fig. 4).
Now fold out both side trays (11), as shown in Fig. 5.
Now t the table in the retainer intended and re-tighten
the star grip screws previously loosened (Fig. 6 (2)).
8.3 Mounting complete control arms (10) (Enclo-
sure bag B)
The control handles on the arms point outwards!
Insert the hexagon screw and washer through the
hole in the control arm (Fig. 7 (1)).
Guide control arm (A) into the rocker switch (B) (Fig.
7 (2)).
Place the washer (7a) between the control arm and
tray (Fig. 7 (2)).
From below, now tighten the hexagon screw with
washer and a self-locking nut.
Attention: Tighten the self-locking nut only su󰀩cient-
ly that the complete control arm can be moved to the
left and right.
Now fasten the other control arm on the other side in
accordance with the method described.
8.4 Fitting the claws (enclosed accessories bag C)
Attach the additional brackets (D) to the claws with
two Phillips screws, washers and nuts each (Fig. 8).
Make sure that the longer additional bracket is at-
tached to the claw (4), the shorter additional bracket
must be attached to the claw (4a).
Place the adjustable claws on the hexagon nuts pre-
viously attached, and fasten these with the star grip
screws and washers enclosed (Fig. 8).
Noise values (230V~)
Sound power level L
WA
97.4 dB
Sound pressure level L
pA
89.8 dB
Uncertainty K
WA/pA
3 dB
* Operating mode S6 40% is an uninterrupted, periodic
mode with intermittent load. The mode comprises of a
start-up period, a time with constant load and an idle
time. The operating time is 10 mins, the relative duty
cycle is 40% of the operating time.
Pressure:
The performance level of the built-in hydraulic pump
can reach a brief pressure level for a splitting force of
up to 7 tons. In the basic setting, hydraulic splitters are
set at the factory to an approx. 10% lower output lev-
el. For safety reasons, the basic settings must not be
changed by the user.
Please note that external circumstances such as oper-
ating and ambient temperature, air pressure and mois-
ture a󰀨ect the viscosity of the hydraulic oil. In addition,
manufacturing tolerances and maintenance errors can
a󰀨ect the reachable pressure level.
7. Unpacking
Open the packaging and carefully remove the device.
Remove the packaging material, as well as the packag-
ing and transport safety devices (if present).
Check whether the scope of delivery is complete.
Check the device and accessory parts for transport
damage. In the event of complaints the carrier must be
informed immediately. Later claims will not be recog-
nised.
If possible, keep the packaging until the expiry of the
warranty period.
Familiarise yourself with the device by means of the
operating manual before using for the rst time.
With accessories as well as wearing parts and spare
parts use only original parts. Spare parts can be ob-
tained from your specialist dealer.
When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
