Hero Eco A2B Alva+ - Removing the Rear Wheel

34
Owner`s manual
Removing rear wheel
1. Ensure that the battery is disconnected.
2. Remove the cable retaining clips using an appropriate allen key also
located on the underside of the left hand chain stay.
3. Disconnect the motor power and motor controls connectors.
4. Using a 19 mm spanner, loosen and remove the hubaxle nuts.
5
3
2
4
7
6
1
5. Loosen and remove the torque arm retention bolt from the left
hand side drop out.
6. Remove the torque arm from the A2B by sliding it off the axle.
7. Remove the rear wheel by sliding it out of the frame while
disengaging the chain from the freewheel.
