HERO Splendor Plus - Page 11

8
9
1112
14
13
(2) Kick start pedal
(3) Rider foot rest
(4) Oil level dipstick
(5) Rear brake pedal
(1) Pillion foot rest
(7) Front suspension
(9) Visor
(8) Headlamp
(6) Utility box
(10) Front brake lever
(12) Seat
(13) Rear turn signal lamp
(11) B attery compartment (inside)
(14) Rear suspension
10
1 2
4
5 6
7
3
*Accessories and features shown may not be part of standard fitment.
