HERO Splendor Plus - Page 10

11
43
6
1 2 5
7
10
8
9
12
(1) Carburetor
(4) Main stand
(2) Gear shift pedal
(3) Rider foot rest
(5) Side stand
(6) Pillion foot rest
(9) Reflex reflector
(8) Saree guard
(10) Tail /Stop lamp
(7) Women pillion step
(11) Rear carrier
(13) Air suction valve
(14) Fuel valve
(15) Clutch lever
(12) Left side cover
131415
*Accessories and features shown may not be part of standard fitment.
