(8) Neutral indicator
(4) Headlamp switch
(5) Headlamp dimmer switch
(7) Odometer
(6) Speedometer
(2) Horn switch
(3) Turn signal switch
(1) Turn signal indicator
(9) Fuel gauge
(10) High beam indicator
(12) Throttle grip
(13) Front turn signal lamp
(11) Rear view mirror
(14) Ignition switch with steering lock
(16) Leg guard
(15) Fuel tank lid
13
*Accessories and features shown may not be part of standard fitment.
