34
(5) Index mark (6) Scale graduation
(1) Rear axle nut (2) Sleeve nut
(4) Drive chain adjusting nut
(3) Drive chain lock nut
5
36-37
“OFF”
the maintenance schedule would ensure
high performance and longer life.
6
3
4
2
NOTE
Visit Authorised Hero MotoCorp workshop
for inspection, cleaning, lubrication and
adjustment of drive chain at every 2000 kms.
Adjustment
1. Place the motorcycle on its main stand.
3. If adjustment is necessary turn the
adjusting nut (3).
2. Measure the distance, the front brake
lever (1) moves before the brake starts
to take hold. Free play (2) should be 10-
20 mm at the tip of the brake lever.
Regular adjustment and lubrication as per
4
