4. Remove the axle nut (7).
3. Disconnect the brake cable (3) from
brake arm (4) and brake panel (5) by
removing the front brake adjusting nut
(6).
5. Remove the axle and then remove the
wheel.
(7)
(5) Brake panel
(6)
(Cast wheel version)
2. Remove the speedometer cable (1) by
pressing the tab (2) & then pull out the
cable.
1. Raise the front wheel off the ground.
35-36
Axle nut torque : 5.4 kgf-m
Tighten the axle nut
Tab
