41
.
Check the rear shock absorber by
pushing hard downwards on rear
carrier while the motorcycle is not
parked on stand. The suspension
action should be smooth and there
should be no oil leakage.
there
5
7
(Spoke wheel version)
2. Remove the speedometer cable (1) by
pressing the tab (2) & then pull out the
cable.
5. Remove the axle and then remove the wheel.
3. Disconnect the brake cable (3) from
brake arm (4) and brake panel (5) by
removing the front brake adjusting nut
(6).
4. Remove the axle nut (7).
(7)
(5) Brake panel
(6)
1. Raise the front wheel off the ground.
6
Tab
