HERSILL V7 Series - Description of the Equipment

4
ENGLISH
4. Description of the equipment
4.1. General description
A. Main unit (casing)
B. Liquids collector bottle
C. Suction tubes (must be changed for each patient).
D. Bacteria filter (must be changed for each patient).
E. Electrical connection cables (depending of the models)
F. ON/OFF switch
G. Vacuum indicator (vacuum-meter)
H. Vacuum regulation control knob
I. LED indicators (only for model V7 m, V7 mx, V7 plus b and V7 plus b emergency)
4.2. Led indicators and vacuum control knob
B
C
C
C
D
E
F
G
H
I
A
Power on LED indicator
External power LED indicator
Battery status LED indicators
Vacuum control knob
