HEWITT 4600 - Page 6

4600 VERTICAL LIFT
KEEL/CRADLE ASSEMBLY
INSTRUCTIONS
PAGE 5
1. Attach keel boards and bunks as shown.
2. Adjust as necessary.
3. Insert 3" x 3" plastic plugs in ends of long bases and cross bases.
CARPETED BUNK
REINFORCEMENT
PLATES
BUNK SIDE
PLATES
CROSS BEAM
2" x 2" BLOCK
2-1/2" CARRIAGE BOLTS
WOOD KEEL BOARDS
8-1/2"
CARRIAGE
BOLT
3/8" x 3-1/2"
Bolt
3/8" x 3-1/2"
Bolt
3/8" x
3-1/2"
Bolt
3/8" x 3-1/2" Bolt
PLUGS
(all corners)
