Cabling 6
Item Description
6 SAS port 2 connector
Using either of the Secondary I/O module drawers for Smart Array Controller cabling is an unsupported
configuration.
Only one SAS port connection on each Primary I/O module is a supported configuration. It is
recommended to connect cables to SAS port 1 connectors.
No cables ship with the MDS600. The only supported cable length that can be used is the 2.00m (6.56
ft.) mini-SAS cable.
8x wide SAS cables are not supported.
Always be sure that the servers attached to the MDS600 are powered down before connecting SAS
cables.
