HEX Alton - Page 10

Assembly Guide
8
FK1
FK5
FK6
LOCATE CORNER POST 0205-14 AS SHOWN ABOVE.
3A 3B
LOCATE AND LOOSELY ATTACH CORNER POST 0205-14.
ASSEMBLY STAGE 3
x2
0205-14
x2 HOLES AT TOP
3B
3A
FK5
IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
LOOSELY ATTACH CORNER POST AT LOCATION INDICATED ONLY.
