HEX Alton - Page 22

Assembly Guide
20
FK1
LOCATE CORNER POST 0205-14 AS SHOWN ABOVE.
IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
LOOSELY ATTACH CORNER POST AT x2 LOCATIONS INDICATED ONLY.
15A 15B
LOCATE AND LOOSELY ATTACH CORNER POST 0205-14 (1885mm).
x2
ASSEMBLY STAGE 15
FK5
19B15B
15B
15A
x2 HOLES AT TOP
0205-14
