HEX Alton - Page 27

Assembly Guide
25
FK1
x2
20B
LOOSELY ATTACH AT x3 LOCATIONS INDICATED ONLY.
LOCATE AND LOOSELY ATTACH WALL PANEL 0205-12 (1850 x 625mm).
ASSEMBLY STAGE 20
FK5
FK1
LOCATE AND LOOSELY ATTACH WALL PANEL AT x3 LOCATIONS INDICATED.
IMPORTANT: ENSURE PANEL IS IN THE CORRECT ORIENTATION.
FK5
INSIDE
OUTSIDE
INSIDE
OUTSIDE
20A
20A
20A
20A
20B
20B
20B
0205-12
