Assembly Guide
30
FK5
LOCATE SHORT ROOF RAIL 0213-02 AS SHOWN ABOVE. LOOSELY ATTACH AT x12 LOCATIONS INDICATED.
25A 25B
ASSEMBLY STAGE 25
LOCATE AND LOOSELY ATTACH SHORT ROOF RAIL 0213-02.
x2
FK1
25A
25B
25B
0213-02
0213-02
25A
