Assembly Guide
29
FK1
24B
LOCATE AND LOOSELY ATTACH LEFT-HAND DOOR POST 0205-17.
LOCATE AND LOOSELY ATTACH SHORT CENTRE BRACE 0213-04 ONTO WALL PANEL.
ASSEMBLY STAGE 24
FK5
24A
INSIDE
OUTSIDE
INSIDE
OUTSIDE
IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
IMPORTANT: DO NOT SECURE AT UPPER FIXING POINT AT THIS STAGE.
SECURE DOOR POST AND CENTRE BRACE AT LOCATIONS INDICATED.LOCATE LEFT-HAND DOOR POST 0205-17 AS SHOWN ABOVE.
IMPORTANT: ENSURE DOOR POST IS IN THE CORRECT ORIENTATION.
24A
24B
24B
0205-17
0213-04
