HEX Alton - Page 49

Assembly Guide
47
x2
ASSEMBLY STAGE 42
LOCATE AND SECURE ROOF PANELS 0252-03 & ROOF PANEL SMALL 0252-06.
0252-06
0252-03 (x2)
42B
42A
42A
42A
42B
42B
INSIDE
OUTSIDE
INSIDE
OUTSIDE
IMPORTANT: ENSURE RUBBER WASHER FK4 IS LOCATED AS SHOWN.
SECURE ROOF PANELS AT LOCATIONS INDICATED USING TYPICAL FIXING METHOD.
42B
FK1
FK4
FK5
42A
ALIGN AND OVERLAP ROOF PANEL WITH PREVIOUS ROOF PANEL.
IMPORTANT: ENSURE PANELS ALWAYS OVERLAP AS SHOWN.
