HEX Alton - Page 56

Assembly Guide
54
FK3
FK5
SECURE EURO MORTICE LOCK 0203-32 AT x2 LOCATIONS INDICATED ABOVE.
SEE FOLLOWING DATA SHEET FOR COMPLETION OF MORTICE LOCK INSTALLATION.
LOCATE EURO MORTICE LOCK 0203-32 RIGHT-HAND DOOR APERTURE
AS SHOWN.
49B49A
ASSEMBLY STAGE 49
LOCATE AND SECURE RIGHT-HAND DOOR ASSEMBLY 0205-36 FURNITURE.
0205-36
0203-32
