ASSEMBLY STAGE 52
LOCATE AND SECURE DOOR HINGES ONTO DOOR ASSEMBLIES.
0203-28
0203-37
0203-280203-27
0203-27
0203-37
0203-37 0203-37
SECURE DOOR HINGE PLATE AND HINGE 0203-27 AND 0203-28 AS SHOWN. LOCATE DOOR HINGE PLATE 0203-37 WITHIN DOOR AS SHOWN.
52A
FK3
IMPORTANT: ENSURE CORRECT DOOR HINGE IS SECURED TO CORRECT DOOR.
FK5
52B
