HEX ECHO Series - 1.4 Size Parameter

echo series Product manual
7 WWW.HEXMAN.CN
1.4 Size Parameter
Figure 1.2 Dimensional diagram (this image shows ECHO with the same dimensions as ECHO-ED)
370MM
380MM
140MM
35MM
100MM
200MM
M4-15
80MM
100MM
245MM
R=295MM
