ACT
Green/Yellow
Yellow blinking
Green blinking PoE On with Activity
Solid Green PoE On with no activity
OFF Non PoE with no activity
Non PoE with activity
LINK
Green/Yellow
Solid Green
Solid Yellow Link Up at 100Mbps speed
OFF No Link
Link Up at 1000Mbps speed
LED Label LED Colour Indication
Status
SM
Blue
OFF
Blinking
Power up sequence
in process
Solid ON
System is booted
and operational
System is powered OFF
ALM
Red
OFF
Blinking Alarm reported
Solid ON Critical alarm reported
No alarms reported
LED Label LED Colour Indication
Status
Port LED status
System LED status
