HHB FlashMic DRM85 - Page 41

User Manual Supplement
FlashMic DRM85-C Features
P4
Your FlashMic combines a professional-quality, uni-directional condenser microphone with
an internal digital audio recorder in a single self-contained, self-powered unit. An
extremely simple set of controls makes it suitable for completely non-technical users;
alternatively, more experienced recordists can access a wide range of additional
functionality through menu-based pages on the FlashMic’s LCD display.
Specifications P38
All specifications are as the omni-directional DRM85, with the exception of:
Microphone capsule Uni-directional (cardioid)
Polar Diagram and Frequency Response Curve
of DRM85-C Cardioid Microphone Head
P39
HPF off
Hz
100 1.000 10.000
dBV
0
-10
-20
-30
-40
-50
50 100 200 500 1k 2k 5k 10k 20k
HPF on
DRM85-C FlashMic Frequency Response Curve
DRM85-C FlashMic Polar Diagram
0°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
1kHz and below
4kHz
8kHz
2kHz
5dB
10dB
15dB
20dB
25dB
