En.5
ENGLISH
FlashMic Description
Protective basket (windshield) over mic capsule
FlashMic body
LCD display – see FlashMic Display Window
Main operating control section
REC button (G)
PLAY button (H)
MENU/STOP button (M)
Multi-function jogswitch control - see Jogswitch Description
Record mode LED (REC LED)
USB connector (5 pin Mini-B)
PHONES: monitor output (3.5mm 3-pole jack socket)
1
2
3
4
USB
MENU
PHONES
10
11
98
