SECTION 4
PARDS ЕГ ЕЛЕ
4-1. INTRODUCTION
Reference designations are assigned to identify all parts of the
Model 60004, Dynamic Mutual Conductance Tube Tester. These desig-
nations are used in the parts list and schematic wiring diagram. The
letter prefix of a reference designation indicates the kind of part --
resistor, capacitor, electron tube, etc.
HICKOK
CAPACITOR, FIXED, MICA: 2700 uut, 3095-41
10%, 500 volts
Са CAPACITOR ОЕ CERAM АР ДЫН 3110-148
500 volts
(52 CAPACITOR, FIXED, CERAMIC: .0lu Е, 3110-64
+100 -20%, 500 volts
С4-СТ Same ав С3
СВ CAPACITOR, FIXED. PLASTIC: POON 3105-206
C9 CAPACITOR ESED “ERE CERO УИС: 3085-45
50 uf, 6 volts
DS1-DS5 |LAMP: NE2, neon, 65УАС, 90VDC, 12270-26
1/25 watt, shorts lamp
Fl LAMP: #81, bayonet type (for 115 volt 12270-2
operation)
F1 LAMP: 763, bayonet type (for 230 volt 12270-58
operation)
F2 LAMP: #49 pilot, 2 volts, bayonet type 12270-17
72 JACK: red, phenolic 10300-47
Ja JACK: black, phenolic 10300-48
М1 METER: 680-298
MP1-MP9|KNOB: bar type, with white dot 11505-46
MP10 КМОВ ASSEMBLY: with pointer 11500-11
MP11 DIAL ASSEMBLY: BIAS 4160-67
MP12 DIAL ASSEMBLY: SHUNT 4160-73
P1 PLUG: octal type, black 16525-186
P2 CORD: AC line 3675-34
E RESISTOR, FIXED, DEPOSITED FILM: 18540-5
200 ohms, 195, 2 watts
R2 RESISTOR: 100 ohms, 10%, 10 watts, 18575-19
center tapped
R3 Not assigned
R4
RHEOSTAT:
350
ohms,
25
watts,
with
off
18750-37
position, LINE ADJUST
RESISTOR, FIXED, COMPOSITION:
1200 ohms, 10%, 1 watt
RESISTOR, FIXED: 1800 ohms, 10%, 10 watts
18422-122
18575-12
