HID Mercury MR52-S3B - Page 12

S8 S7 S6 S5 S4 S3 S2 S1 Selection
ON ON ON ON ON Address 31
OFF OFF 115,200 BPS
1
OFF ON 9,600 BPS
ON OFF 19,200 BPS
ON ON 38,400 BPS
OFF Encrypted communication not required
2
ON Encrypted communication required
2
1. Firmware revisions prior to 1.38.1, this setting is 2,400 BPS.
2. Firmware revisions prior to 1.38.1, SW8 is not defined. Set to the OFF position.
