HiFiMAN EF499 - Front Panel Layout; Front Panel Controls and Indicators; Front Panel Audio Outputs

05
EF499 User Guide
Front Panel Layout
*4-level Function Switch
Volume Control
Low Gain NOS Indicator
Low Gain OS Indicator
High Gain OS Indicator
High Gain NOS Indicator
XLR 4-Pin Balanced
Headphone Output
6.35mm Single-ended
Headphone Output
* When operates the 4-level function switch,
the corresponding functions of the LED lights (white) are:
High Gain NOS, High Gain OS, Low Gain OS, Low Gain NOS
