Super Sniper 90 Technical Data
Wingspan: 1120 mm (44’’)
Length: 1200 mm (47.2’’)
Weight: 2400 ~ 2800 grams depending on power setup
Fan Size: Single 90mm Electric Ducted Fan Unit
RC Equipment needed to complete the model:
• 3-5 channel Computer Radio with 3-6 Servos
o 3x HS-82MG for Aileron & Elevator
o 1x HS-81MG for Rudder (optional)
o 1x HS-81MG for Nose Gear Steering (optional)
o 1x HET-9gram for Retract Valve (optional)
• 90mm Fan unit (e.g. HET-RC 9305)
• 600 Brushless Motor (e.g. HET-RC Typhoon 600-42)
• Brushless Speed Controller (e.g. HET 90A ESC)
• LiPo Battery to match Motor and ESC (e.g. 3700mAh 7S 30C)
Building equipment required:
• 30 min epoxy
• 5 min epoxy
• Milled fiberglass
• Micro Balloons
• Drill (e.g. Dremel tool) with 1, 1.5 and 2mm drill
• X-acto Knife
• CA Glue with accelerator
• Sandpaper (220-180)
A rotary tool, such as a Dremel, will greatly help in the building process.
A drum sander and cutting disk is highly recommended to cut the necessary
retract openings into the fiberglass fuselage.
