3 Press button to go to the setting
interface.
 Emissivity: Set the emissivity of your
target as the effectiveness in emitting
energy as thermal radiation.
Note: Refer to the 6.1 Common
Material Emissivity Reference for
emissivity values.
 Temperature: Set the average
temperature of the environment.
 Distance (m/feet): Set the straight-line
distance between the target and the
device.
Note: The recommended
thermometry distance is 0.2 m to 2
m with target size 80 × 80 mm.
 Rule: Select Hot Spot, Cold Spot to
show the max. temperature, min.
temperature in the live view interface.
4 Press / button to select
desired parameter, and press
button to enable it.
5 If necessary, press / button
to increases / decrease the setting
values. Hold / button to
change the value quickly.
6 Press button to save and exit.
4.2 Other Configurations
Here is an example of setting laser light
function.
Steps:
1 In the live view interface, press
button show the menu bar.
2 Press / button to select
Laser.
3 Press button to turn on / turn off
laser light function.
4 Press button to save and exit.
5 In live view interface, pull the trigger to
turn on laser light, release the trigger to
turn off laser light.
Note: Other parameters, such as temperature
measurement range, unit, palettes and so on,
can be configured as steps above.
5 System Information
Go to Menu > About to view the device
information: Model, Version No., FPGA Version
No., Serial No., Capacity and so on.
You can also set the auto power-off duration,
date and time in Menu.
