Hikmicro E1L - Device Appearance and Interfaces; Dimensions and Physical Layout; User Interface and Controls

2 Appearance
2.1 Dimensions
59mm(2.32")
196mm(7.72")
78mm(3.07")
The dimension may vary according to different
camera model.
2.2 Interfaces
Screen
Charging
Indicator
Back
Navigation
On/OK/Menu
Hold: Power On/Off
Press: Display menu or confirm
operation
Exit the menu or return to
previous menu.
Navigation Button
Press the ▽, △button to select
parameters.
Press the button to
confirm
