3. Install Camera (Page 2 – B)
Before installation, make sure that the installation surface is strong
enough to withstand four times the weight of the device and the
accessory. Check the specification of the products for the installation
environment.
Select a desired installation method from B.1 to B.4.
Installation Method and Steps
Method
Steps
B.1
1. Attach the device to a ferromagnetic surface.
B.2
1. Paste the drill template to the installation surface.
2. Drill 4 screw holes (Ø3 mm) according to the “2” holes.
3. Screw the device to the surface with 4 supplied M3×10.
B.3
1. Paste the drill template to the installation surface.
2. Drill 4 screw holes (Ø3.5 mm) according to the “1” holes.
3. Screw the device to the surface with supplied M3×15
screws and M3 nuts.
B.4
Purchase a PT joint in advance.
1. Disamble the PT joint.
2. Install the PT joint base to installation surface, and then
install the PT joint bracket back.
3. Fix the device to the PT joint bracket.
