Hikmicro HM-TD3117T-1/Q Quick Start Guide

5
English
1. Introduction
Thermographic Cube Camera Series is able to measure object’s
temperature at a high accuracy in real time. For the model with 433 MHz
data transmission function, it is capable of wireless data transmission
among different transducers and gateways. It is often applied to electric
system, industrial automation, etc. for fire prevention. The pre-alarm and
network system helps you discover unexpected events immediately and
protects your property effectively.
2. Appearance (Page 1 – A)
Component & Interface
No.
Component
Description
1
Magnatic
Installation
Panel
Installation panel. Choose one of the following
ways to mount the device
● Attach the device to a ferromagnetic surface
● Screw the device to installation surface.
2
Power Indicator
● Solid Red: Start normally.
● Solid Green: Work normally.
3
Network
Indicator
● Solid Yellow: Network connection failed.
● Flashing Yellow: Network connection
succeeded.
4
Thermal Lens
Aiming at targets for temperature
measurement
5
Reset Button
To reset the device, you need to hold the reset
button to boot it. Then keep holding the reset
button for 5 seconds, and wait until the power
indicator turns from red to green.
6
Cable Connector
Aviation plug, female.
7
Cable Connector
Aviation plug, male. Screw the male connector
clockwisely to fix the cable.
8
Serial Port
For debugging
9
RS-485 Port
For RS-485 communication
10
Power Supply
12 VDC input
11
Network
RJ45 Network Interface, 100 Mbps
