Hikmicro Pocket Series Quick Start Guide

2
No.
Description
Function
7
Power Key
Hold to power on/off the device.
8
Capture Key
 Press: capture snapshots/stop recording
 Hold: start recording
9
Tripod Mount
Mount the tripod.
10
Strap Attachment Point
Mount the strap.
11
Indicator
Indicate the charging status of the device.
 Solid red: charging normally
 Flashing red: charging exception
 Solid green: fully charged

Hikmicro Pocket Series Specifications

General

Wi-Fi	Yes
Laser Pointer	Yes
Accuracy	±2°C or ±2%
Image Modes	Thermal, PIP
Battery Type	Li-ion Battery
Sensor Type	Uncooled VOx microbolometer
Spectral Range	8 to 14 μm
Resolution	384 × 288 (Pocket2)
