HIKVISION DS-1005KI How To Use

3 How to use 1005KI with iVMS-4200
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
3. Restart iVMS-4200 to take the configuration into effect, connect 1005KI to USB port of PC,
and the keyboard will be auto-detected
4. Operation of keyboard
1) Default operation under USB joystick mode(two lights on)
Keyboard is under window switching mode once connected, you can use Joystick to select
different window
Click right button on joystick to change keyboard to PTZ control mode, use joystick to
control PTZ
2) Default operation under USB keyboard mode(one light on), long click on keyboard
to change mode
① With on, use joystick to control PTZ, left button on joystick means record with
and right button means capture picture
② With on, press Num+ button to select different window

HIKVISION DS-1005KI Specifications

General

Type	Joystick
Product color	Black, Silver
Placement supported	Universal
Programmable buttons	Yes
Number of joystick axis	3
Number of programmable buttons	15
Connectivity technology	Wired
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	5 V
Harmonized System (HS) code	85299020

Weight and Dimensions

Depth	177.5 mm
Width	167 mm
Height	116 mm
