Sharpness function enhances the detail of the image by sharpening the edges in the image. The
value ranges from 0 to 100.
Exposure Settings
Exposure Mode
The Exposure Mode can be set to Auto, Iris Priority, Shutter Priority, and Manual.
Auto:
The iris, shutter and gain values will be adjusted automatically according to the brightness
of the environment.
Iris Priority:
The value of iris needs to be adjusted manually. The shutter and gain values will be
adjusted automatically according to the brightness of the environment.
Figure 6-25 Manual Iris
Shutter Priority:
The value of shutter needs to be adjusted manually. The iris and gain values will be
adjusted automatically according to the brightness of the environment.
Figure 6-26 Manual Shutter
Manual:
In Manual mode, you can adjust the values of Gain, Shutter, Iris manually.
Figure 6-27 Manual Mode
