Explosion-Proof Optical & Thermal Network Bullet Camera·Quick Start Guide
28
4). Connect the power cables with the connector, and then
connect the video cables.
Sealing Ring
Top Cable
Gland
Bottom
Cable Gland
Figure 3-13 Connect Cables
7. Cover the junction box with the screws.
