Explosion-Proof Optical & Thermal Network Bullet CamerQuick Start Guide
23
Figure 3-5 Assemble the PT Joints
5. Drill four holes in the wall with a Φ10 drill, and drill four expansion
screws into the holes.
Expansion Screws
Wall
Figure 3-6 Drill Expansion Screws into the Holes
