HIKVISION DS-2TD2528T-7/Q User Manual

Explosion-Proof Optical & Thermal Network Bullet Camera·Quick Start Guide
24
6. Align the four holes on the bracket with the four expansion screws
on the wall, install the whole device (with the bracket) on the wall,
and tighten the screws.
Wall
Expansion Screw
Figure 3-7 Screw the PT Joint to Wall Mounting Bracket
7. Adjust the tilting position of the camera, and fix the camera to the
bracket.
Figure 3-8 Install the Camera with Bracket

HIKVISION DS-2TD2528T-7/Q Specifications

General

Brand	HIKVISION
Model	DS-2TD2528T-7/Q
Category	Security Camera
Language	English
