HIKVISION DS-2TD8166-150ZH2F/V2 Quick Start Guide

Thermal Network Speed Dome Quick Start Guide
12
Figure 3-12 Route the Cables
4. Install the dome body to the head cover for camera type III
1). Hook the two ends of the safety rope to the back box of the speed dome and the
bracket respectively.
Safety Rope
Figure 3-13 Hang the Speed Dome
2). Route the cables through the head cover and bracket.

HIKVISION DS-2TD8166-150ZH2F/V2 Specifications

General

Brand	HIKVISION
Model	DS-2TD8166-150ZH2F/V2
Category	Security Camera
Language	English
