DS-6900UDI Series Decoder Quick Start Guide
8
Front Panel Description
Rear Panel Description
No.
Description
No.
Description
1
Power supply indicator, red for normal
working status
4
1000 M optical interface
2
HDMI in interfaces
5
USB 2.0 interface
3
1000 M electrical interface
When the electrical interface is
connected, the transmission status
indicator on the upper left of the
interface is flashing yellow, and the
connection status indicator on the upper
right is unlit.
6
RS-232 interface
No.
Description
No.
Description
1
Audio output interface
6
Alarm output interfaces
2
Video output interface
7
Alarm input interfaces
3
HDMI out interfaces
8
RS-485 interface
4
Line in interface
9
Power input
5
Line out interface
10
Power supply fan
