HIKVISION DS-K2802 Quick Start Guide

DS-K2800 Serial Access Controller
7
DS-K2801 Terminal Description Table 3-1
No.
DS-K2801
A1
Power
GND
DC12V Grounding
A2
+12V
DC12V Input
A3
Door
NC
Door Lock Relay Output
A4
COM
A5
NO
A6
BUTTON
Door Button Input
A7
GND
Grounding
A8
SENSOR
Door Magnetic detector
B1
Alarm Output
COM
Alarm Relay Output (Dry Contact)
B2
NO/NC
B3
Alarm Input
GND
Grounding
B4
IN
Alarm Input
B5
Wiegand Card Reader 1
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B6
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B7
BZ
Card Reader Buzzer Control Output
B8
W1
Wiegand Head Read Data Input Data1
B9
W0
Wiegand Head Read Data Input Data0
B10
PWR
Card Reader Power Output
B11
GND
B12
Wiegand Card Reader 2
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B13
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B14
BZ
Card Reader Buzzer Control Output
B15
W1
Wiegand Head Read Data Input Data1

HIKVISION DS-K2802 Specifications

General

Product type	Access controller
Certification	CE, FCC
Compatibility	Wiegand
Mounting type	Wall
Product color	Black
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	285 mm
Width	237 mm
Height	69 mm
